Art. No. 1423629

PTU 31 P MN SMART

Paper towel dispenser for dispensing all major paper types

Material
  • Stainless steel
Paper type
  • C-fold, Layerfold / Z-Fold / ZZ-Fold, V-Fold, Zick-Zack / Multi- and Interfold
Lock
  • SanTRAL vandalism-proof lock, plastic
Smart function
Colour
Quantity:
  • Description
  • Documents
  • Technical Drawings
  • Spare parts

SanTRAL® Plus PTU 31 P Midnight (MN) SMART, paper towel dispenser, for max. of 2 packs of paper towels (approx. 500-600 sheets), stainless steel, matte black powder coated (RAL 9005), universal SanTRAL® Plus stainless steel removal for all common types of paper (Layerfold, V-, Z- and ZZ-fold, Multi- and Interfold), lockable, with fill level window, sloped-top housing prevents placement of unwanted objects on dispenser

Data transmission via WiFi with visualization by KANARY or third party platforms, for fully automatic detection of the fill level via sensor technology, integrated LEDs to indicate a critical battery and fill level, over-the-air configuration and firmware update, NFC to read out data and to configure via smartphone.

Quantity / Pallet EU:80
Product Type:Paper towel dispenser
Housing:Stainless steel, matte black powder coated (RAL 9005)
Material:Stainless steel
Filling volume (sheet):approx. 500-600 sheets
Paper type:C-fold, Layerfold / Z-Fold / ZZ-Fold, V-Fold, Zick-Zack / Multi- and Interfold
Smart function:Smart
Lockable:Yes
Lock:SanTRAL vandalism-proof lock, plastic
Batteries:4x AA alkaline batteries, 1.5 V, exchangeable, non-rechargeable
Electronic:Board with sensors, WiFi module 802.11 b/g/n (Frequency range: 2400 MHz - 2483.5 MHz; WPA and WPA2) and NFC Chip (Frequency: 13.56 MHz)
Firmware:Updates and configuration “over-the-air” (OTA)
Voltage:6 Volt
Compliancy:RoHS
CE certification:EN 300328 Integration verification WLAN, EN 300330 Integration verification NFC, ETSI EN 62311.2008 EMF, ETSI EN 301489-1 EMV
Software:Dispenser with integrated Smart Module enables automatic fill level detection and connection to KANARY as well as third-party platforms
Mounting:Wall mounting with 4 screws and wall plugs
Cleaning:manual wipe disinfection, not dishwashersafe, not autoclavable
Warranty:5 years
